Spektrum DX8e DSM-X 2.4Ghz 8ch Radio (Transmitter only - SPMR8105)
Overview
Upgrading from a limited 6-channel radio to a far more versatile 8-channel radio with computer functionality on a budget doesn’t mean you have to settle for less than the best. The Spektrum™ DX8e gives you the unbeatable response of DSMX® technology, the simplicity of Spektrum AirWare™ firmware as well as many other features you won’t find on other “budget” radios.
Your growing skills deserve a transmitter than can keep pace. The DX8e comes equipped with the programming you need, no matter what you fly. And because it’s based on the same Spektrum AirWare firmware used in most other Spektrum transmitters, you can share model setups with just about any Spektrum user you meet.
With the flexibility 8-channels delivers, it’s exciting to consider all the options many modern aircraft can accept. Aircraft with flaps, retracts and SAFE® select can now all be flown to their full potential. With its extra channels at the ready, you can consider adding lights to a switch or a simulated bomb drop option. Try out what extra flight modes and mixes can offer, play with gain settings on the AS3X® system—all without sacrificing premium functions you enjoy like flaps, retracts or dual-ailerons and elevators.
Airplane Programming
- 7 Wing Types: Normal, Dual Aileron, Flaperon, 1 Aileron 1 Flap, 2 Aileron 1 Flap, Elevon A, Elevon B
- 6 Tail Types: Normal, V-Tail A, V-tail B, Dual Elevator, Dual Rudder, Dual Rudder/Elevator
- Flap System with Elevator Compensation
- 3 Flight Modes
- Dual Rates and Expo
- 7-Point Throttle Curve
- 3 Preset Mixes: Rudder-to-Aileron/Elevon, Aileron-to-Rudder, Elevator-to-Rudder
- 4 Programmable Mixes—Normal or Curve
Helicopter Programming
- Gyro
- 7-Point Throttle Curve
- 7-Point Pitch Curve
- 7-Point Tail Curve
- 2 Swash Plate Types: Normal, 3-Servo 120°
- 3 Flight Modes + Throttle Hold
- Dual Rates and Expo
- Cyclic-to-Throttle and Swash-plate Timing Mixes
- 4 Programmable Mixes—Normal or Curve
Sailplane Programming
- 4 Wing Types: Single Aileron, Dual Aileron, 2 Aileron 1 Flap, 2 Aileron 2 Flap
- 3 Tail Types: Normal, V-Tail A, V-Tail B
- Camber System
- Camber Preset
- 5 Flight Modes
- Dual Rates and Expo
- 4 Preset Mixes: Aileron-to-Rudder, Aileron-to-Flap, Elevator-to-Flap, Flap-to-Elevator
- 4 Programmable Mixes—Normal or Curve
Multirotor Programming
- Multirotor Channel Inputs—ALT (Altitude), ROL (Roll), PIT (Pitch), YAW
- Multirotor Checklists and Warnings
- Simplified Multirotor Flight Mode Setup and Switch Assignment
- 8-channel flexibility and accessibility
- Airplane, Helicopter, Sailplane and Multirotor programming
- Smooth quad-bearing gimbals with multi-point front-access adjustments
- Ultra-simple Patent-Pending gimbal mode-change switch
- Built-in telemetry and warning system
- Wireless Trainer link easily connects compatible radios together
- 250 internal model memory, plus external SD card memory support
- High-resolution backlit LCD display
- Practically indestructible adjustable antenna and case design
- VTX control lets you change video channels directly from the DX8e
- Digital Switch adaptability
- Integrated FPV racing lap timer function
- AS3X® technology gain adjustments without a PC
- Multirotor flight mode setup
- 7 airplane wing types and 6 tail types
- 2 swashplate types
- 4 sailplane wing types and 3 tail types
- 7-point throttle curves for airplanes and helicopters
- 7-point pitch and tail curves for helicopters
- Cross-platform model sharing with other Spektrum™ transmitters
- 4 AA batteries included
- EN328 compatible
- Band: 2.4GHz
- Channels: 8
- Flight Modes: 4
- Frame Rate: 11/22 Ms
- Model Memory: 250
- Modes: User Selectable Mode 1-4
- Modulation: DSMX/DSM2
- Proportional Inputs: 5
- Range: Full
- Rate Positions: 3 POS
- Resolution: 2048
- SD Card/Airware Capable: Yes
- Telemetry: Integrated
- Transmitter (Tx) Battery Type: AA
- Type: Entry-level Computer
- Box size: L 31 x W 23.4 x H 14
Transmitter | |
---|---|
TX Channels: | 8 |
TX Operating Frequency: | 2.4Ghz |
Controls Layout: | Stick |
Mode 1/2/3/4: | 1,2,3,4 |
Telemetry Capable: | Yes |
Programmable Failsafe: | Yes |
Included items
Description | QTY |
---|---|
Spektrum DX8e (Transmitter Only) | 1 |
User Manual | 1 |
Required items (not included)
- Spektrum DSMX®/DSM2® Receiver
- 4 x AA Batteries
