Hobbywing QUICRUN 10BL60 Waterproof 60A Brushless ESC - 30102604

Hobbywing QUICRUN 10BL60 Waterproof 60A Brushless ESC - 30102604

by technohobbies.com.au
$129.00

Hobbywing QUICRUN 10BL60 Waterproof 60A Brushless ESC - 30102604

The QuicRun WP 10BL60 ESC brushless sensorless is specially designed for new beginners and intermediate modelers. This ESC is applicable to all-weather sport of 1/10th Short Course Trucks, Buggies and Monster Trucks.

Overview

Hobbywing EzRun Max10 G2 80A waterproof brushless ESC for 1/10 scale, supporting 2-3S LiPo with full G2 programming options.

  • 80A continuous / 520A peak for capable 1/10 scale performance
  • Supports 2-3S LiPo input voltage
  • Waterproof construction for all-terrain reliability
  • Multiple programming options: LED box, LCD box (G2), OTA, and dedicated programming port
  • Firmware upgradeable for future-proofing

The Hobbywing EzRun Max10 G2 80A Brushless ESC is a waterproof 1/10th scale sensored/sensorless speed controller rated at 80A continuous and 520A peak, supporting 2-3S LiPo input. It supports multiple programming methods including LED program box, LCD program box (G2), OTA programmer, and a separate programming port, with firmware upgrade support.

Note

Brushless electric motors and ESCs have huge amounts of torque at any given RPM. Using too-tall gearing, or a vehicle that is too large/heavy, can result in damage and/or product failure. Please consult your manual and select gearing suitable for the vehicle and terrain, as damage caused by overloading or abuse is unlikely to be covered by the manufacturer's warranty. Always monitor your ESC and motor temperatures closely after modifying your system to ensure they stay within the safe operating limits.




HobbyWing QuicRun Max10 G2 Features:

  • High Reliability & Durability
  • Efficient Cooling System
  • Easy Operation
  • Applicable to All Weather Conditions
  • Built-in BEC
  • Multiple programming options:

Specifications

  • Scale: 1/10th
  • Brushed/Brushless: Brushless
  • Sensored/Sensorless: Sensorless
  • Waterproof: Yes
  • Cont./Peak Current: 80A / 520A
  • Input: 2-3S LiPo/6-9 Cells NiMH
  • BEC Output: Switch Mode: 6V / 7.4V, 5A
  • Input Wires: Red 12AWG-159=0mm x1, Black 12AWG 150mm x1
  • Output Wires: Black-14AWG-100mm*3
  • Input Connectors: XT60
  • Output Connectors: 4.0 Gold Connector (Female)
  • Fan Size: 25 x 25 x 25mm
  • SET Button Programming: No
  • LED Box Supported (G2)
  • OTA Programmer Supported
  • Programming Port - Separate
  • Firmware Upgrade - Supported
  • Size: 53mm x 39.5mm x 37.2mm
  • Weight: 120g (with wires)



  • ESC (Electronic Speed Controller)
    For Motor Type: Brushless
    Max Voltage: 11.1v
    Waterproof Design: Yes
    Continuous Amps: 60
    Motor Connectors: 4.0mm Bullet
    Battery Connector: XT60
    Low Voltage Cut off (LVC): Yes
    Programmable: Yes
    Cooling Method: Fan
    BEC Voltage: 6V, 7.4V
    Dual Motor: No
