Hobbywing EzRun Max10 G2 140A Brushless ESC - 30102603

Hobbywing EzRun Max10 G2 140A Brushless ESC - 30102603

by technohobbies.com.au
$129.00

Hobbywing EzRun Max10 G2 140A Brushless ESC - 30102603

The QuicRun WP 10BL60 ESC brushless sensorless is specially designed for new beginners and intermediate modelers. This ESC is applicable to all-weather sport of 1/8 and 1/10th Short Course Trucks, Buggies and Monster Trucks.

Overview


Hobbywing EzRun Max10 G2 140A waterproof brushless ESC for 1/10 scale, supporting 2-4S LiPo with full G2 programming options.

  • 140A continuous / 880A peak current rating for high-performance 1/10 scale builds
  • Supports 2-4S LiPo for versatile power configurations
  • Waterproof construction for all-terrain use
  • Multiple programming options: LED box, LCD box (G2), OTA, and dedicated programming port
  • Firmware upgradeable for future-proofing

The Hobbywing EzRun Max10 G2 80A Brushless ESC is a waterproof 1/10th scale sensored/sensorless speed controller rated at 80A continuous and 520A peak, supporting 2-3S LiPo input. It supports multiple programming methods including LED program box, LCD program box (G2), OTA programmer, and a separate programming port, with firmware upgrade support.

Note

Brushless electric motors and ESCs have huge amounts of torque at any given RPM. Using too-tall gearing, or a vehicle that is too large/heavy, can result in damage and/or product failure. Please consult your manual and select gearing suitable for the vehicle and terrain, as damage caused by overloading or abuse is unlikely to be covered by the manufacturer's warranty. Always monitor your ESC and motor temperatures closely after modifying your system to ensure they stay within the safe operating limits.




HobbyWing QuicRun Max10 G2 Features:

  • High Reliability & Durability
  • Efficient Cooling System
  • Easy Operation
  • Applicable to All Weather Conditions
  • Built-in BEC
  • Multiple programming options:

Specifications

  • Scale: 1/10th
  • Brushed/Brushless: Brushless
  • Sensored/Sensorless: Sensorless
  • Waterproof: Yes
  • Cont./Peak Current: 140A / 880A
  • Input: 2-4S LiPo
  • BEC Output: Switch Mode: 6V / 7.4V, 5A
  • Input Wires: Red 12AWG x1, Black 12AWG 150mm x1
  • Output Wires: Black-14AWG-100mm*3
  • Input Connectors: XT60
  • Output Connectors: 4.0 Gold Connector (Female)
  • Fan Size: 30 x 30 x 10mm
  • SET Button Programming: No
  • LED Box Supported (G2)
  • OTA Programmer Supported
  • Programming Port - Separate
  • Firmware Upgrade - Supported
  • Size: 53mm x 39.5mm x 37.2mm
  • Weight: 120g (with wires)


  • ESC (Electronic Speed Controller)
    For Motor Type: Brushless
    Max Voltage: 11.1v
    Waterproof Design: Yes
    Continuous Amps: 140
    Motor Connectors: 4.0mm Bullet
    Battery Connector: XT60
    Low Voltage Cut off (LVC): Yes
    Programmable: Yes
    Cooling Method: Fan
    BEC Voltage: 6V, 7.4V
    Dual Motor: No
